Outdoor Activities 6082 T6 Aluminum Foldable Truss With Customized Shaped
| Place of Origin | Guangzhou,China |
|---|---|
| Brand Name | LEDIKA |
| Certification | TUV,ISO9001 |
| Model Number | SQS/SQB/TR |
| Minimum Order Quantity | 1set |
| Price | USD100-300/M |
| Packaging Details | Carton with film / Flight case / Wooden box |
| Delivery Time | 15-20 working days |
| Payment Terms | T/T, L/C, Western Union |
| Supply Ability | 50,000M per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Aluminum 6082-T6 | Truss Shape | Square, Triangle, Circular |
|---|---|---|---|
| Specialty | Hanging LED Screen, Speaker And Background Cloth | Max Span | 20-36m |
| Truss Length | 0.5m-4m | MOQ | 1set |
| Loading Port | Guangzhou, China | LOGO | Ledika / Customized |
| Highlight | foldable truss,exhibit truss |
||
Product Description
6082 T6 Aluminum Folding Truss With Customized Shaped For Outdoor Activities
Product Description
1.It is made by 6082-T6 aluminum alloy, which is a highly versatile and cost effective.
2.It is durable and absolutely environmental friendly.
3.It is light weight-easy to carry around, store and transport.
4.It has High quality-strong loading capability.
5.It has favorable price-with competitive price under the assurance of quality.
Product's Material
| Material | 6082 Aluminum |
| Color | Silver, Black, Red, Green or Customized |
| Standard | TUV, ISO9001 |
| Shape | Square, Triangle, Customized |
Specification
| Truss Shape | Connection Type | Specification of Size/mm | Joint |
| Square | Spigot | 600x1200 | Ø 60mm Spigot |
| Triangle | Spigot | 520x470 | Ø 60mm Spigot |
| Triangle | Spigot | 520x950 | Ø 60mm Spigot |
1) FT5247 Aluminum triangle folding truss
Truss size : 520x470mm
Material of folded part: A380
Main tube : Diameter Ø50mm, Thickness 4mm
Joint : Diameter Ø60mm spigot
Standpipe : Diameter Ø30mm, Thickness 2mm
The largest safety loading : 1179-2809kgs
Max Span : 20m
2) FT5295 Aluminum triangle folding truss
Truss size : 520x950mm
Material of folded part: A380
Main tube : Diameter Ø50mm, Thickness 4mm
Joint : Diameter Ø60mm spigot
Standpipe : Diameter Ø30mm, Thickness 2mm
The largest safety loading : 1055-1898kgs
Max Span : 36m
3) FT60120 Aluminum square folding truss
Truss size : 600x1200mm
Material of folded part: A380
Main tube : Diameter Ø50mm, Thickness 4mm
Joint : Diameter Ø60mm spigot
Standpipe : Diameter Ø30mm, Thickness 2mm
The largest safety loading : 1100-2800kgs
Max Span : 20m
Features
1.Portable folding truss system designed to enhance any mobile set up at any size venue
2.Quick and easy set up and tear down with pre-labeled connections and quick release pins
3.Enhances durability and corrosion resistance with aluminum construction
4.Holds up to 1000-2800KG (evenly distributed) when fully assembled
5.Designed to LEDIKA COMPANY
6.Match any setup with selectable height options
Application
1)Performing Arts Stage Equipment
2)Exhibition Truss Equipment
3)Mechanical Stage Design
4)Entertainment Equipment Rental Services
5)Project Design and Installation
Pictures
