Irregular Shape Aluminum Square Truss Party / Concert Stage Truss System
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | 6082 T6 Aluminum | Shape | Star, Heart Shape, Irregular Shape（customized） |
|---|---|---|---|
| Color | Silver, Black, Red | Application | Party, Concert |
| Circular Length | 4 - 12 Meters | Tube Size | 50*3mm |
| Connector | Spigot / Bolt | ||
| High Light | square truss,spigot truss |
||
Product Description
Creative Irregular Shape Aluminum Square Stage Pentagram / Heart Shape
Product analysis:
This is the biggest size in our whole truss system now.It is developed for those applications and circumstances where no current truss solution will fit meet your deemand . The SN1100*600 is mainly for the towers or other support structures .
The main characteristics are compactness, optimum strength and easy assembly with the box corner system .It offers a flexible and strong truss system that is suitable for many designers .
| SN1100*600mm Square Truss Load Table (unit:mm) | ||||||
| Span | 8 | 16 | 25 | 32 | 38 | 44 |
| Centre Point Load | 6500 | 3000 | 1950 | 1200 | 950 | 650 |
| Deflection | 13 | 52 | 90 | 220 | 320 | 230 |
| Distributed Load | 1250 | 6000 | 3900 | 2500 | 1900 | 1400 |
| Deflection | 15 | 65 | 107 | 259 | 360 | 500 |
| Size | W*D*H:SN1100mm*600mm*1000mm--4000mm |
| Material | Aluminum 6082-T6 16 degree |
| Model Number | SN1100mm*600mm |
| Brand Name | |
| Main Tube | 60mm*7mm |
| Sub-main tube | 50mm*4mm |
| Brace tube | 32mm*3mm |
| Place of Origin | China (Mainland) |
| China (Mainland) | Guangdong |
| Name | Square Spigot Aluminum Truss |
| Profile | Aluminum Alloy |
| Loading Capicity | Safe Reach to 24m with 1000kg Average |
| Shape | Square |
| Usage | For Event And Exhibition |
| Color | Silvery and black or customized |
| Type | Spigot |
| Certification | TUV,CE,SGS |
| Size | irregularity size ,as customer request |
| Feature | High Corrosion Resistance , easy to install and demount , long service life , recyclable , multi-purpose , high loading capacity |
| Characteristics | Durable , high loading capacity.Raw material is aprecipitation hardening aluminum alloy,galvanization , containing magnesium and silicon as its major alloying elements . It has good mechanical properites, exhibits good weldability. It also has good effect of Proof Stress , corrosion resistance, antioxidation. |
| Truss system: | to hold events( for light, LED, speaker, audio, and so on) |
| Custom lenghts and shapes in metric and imperial sizes are available on request. | |
