Light Duty Triangle 6082 Aluminum Stage Truss For Project Build
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Truss Model | TRB30/TRB40 | Material | Aluminum Alloy 6082-T6/6061-T6 |
|---|---|---|---|
| Color | Silver,black Or As Your Requirements | Application | Concert,Exhibition,Performance,DJ Band,Event,Fashion Show,etc |
| Main Tube | 50*3mm | Size | 300mm*300mm;400mm*400mm; Customized Available |
| Brace Tube | 30*2mm,25*2mm,20*2mm,as Your Budget | Connection Way | Screw Connector |
| Feature Of Truss | Light Weight,Durable,convenient To Install And Dismounting,Stable And High Quality | Our Advantage | Easy To Installation,Factory,save Labor Cost,competitive Price |
| Packing | Bubble Film /carton | Loading | 500-1500kg According To Size |
| High Light | 6082 Aluminum Stage Truss,Triangle Aluminum Stage Truss,Light Duty Aluminum Stage Truss |
||
Product Description
Light Duty Triangle Aluminum Stage Truss For Project Build
Product Description
In the action of project building , our designers will connect circlar truss or curved truss with other trusses, so that make different diameters or degrees. We will also customize trusses of different shapes according to the different needs of customers. For example , "S"truss ,180 degree truss etc.
Product Parameter
| TRB30 , Material:6061-T6 , Main Tube : 50*3mm , Brace Tube:25*2mm | ||||||||
| Span | Load All | Load/M | Middle point | 2 point | 3 point | 4 point | Deflection | |
| ( M ) | ( ft ) | ( KG ) | ( KG ) | ( KG ) | ( KG ) | ( KG ) | ( KG ) | ( mm ) |
| 4 | 13.1 | 781.4 | 195.4 | 390.7 | 293 | 195.4 | 162.6 | 5 |
| 5 | 16.4 | 624.8 | 125 | 312.4 | 234.3 | 156.2 | 130 | 13 |
| 6 | 19.7 | 522.7 | 87.1 | 261.4 | 196 | 130.7 | 108.8 | 22 |
| 7 | 23 | 443.5 | 63.4 | 221.8 | 166.3 | 110.9 | 92.2 | 33 |
| 8 | 26.2 | 387.2 | 48.4 | 193.6 | 145.2 | 96.8 | 80.5 | 45 |
| 9 | 29.5 | 340.6 | 37.8 | 170.7 | 128 | 85.4 | 71.1 | 59 |
| 10 | 32.8 | 308 | 30.8 | 154 | 115.5 | 77 | 64 | 75 |
| 11 | 36 | 280.7 | 25.5 | 140.8 | 105.6 | 70.4 | 58.6 | 92 |
| 12 | 39 | 253.4 | 21.1 | 126.7 | 95 | 63.4 | 52.7 | 110 |
Why choose LEDIKA Truss ?
1. 21-year's experience in truss and stage industry.
2. Customers from more than 150 countries.
3. We are manufacture, can offer you lower price.
4. Professional engineers offer technical support to customers.
5. 24hours online services from our professional foreign trade department.
6. All our raw material is from public company.
7. Our complete QC system can make sure every product with high quality.
FAQ
Q. Does LEDIKA accept OEM/ODM service ?
Yes , you can custom design or selected our design (OEM /ODM is high welcome) , our factory have professional design team and can do as your offered design .
Q: How to get samples from LEDIKA?
a.If you need samples for quality check , sample fees should be charged from buyer .
b.Free sample are available when order confirmed.
c.Most of the sample fees will be returned to you when order confirmed.
Q: What is the delivery time ?
A: 7-15 days for batch goods regular size truss are in stock . Urgent order is also available.
Q: What is your trade terms?
A: Our trade terms are Ex-work , FOB , CNF & CIF
Q: Where is your factory and how can I visit your company ?
A: Ledika is a professional manufacturer in stage equipment, located in Nansha ,Guangzhou ,GuangDong , China . Warmly welcome you come to visit our factory .
Q: What advantage do you have to make me choose LEDIKA stage truss ?
A: We are a true factory & specialized in producing aluminum truss & other performance equipment more than 13 years . Humanist ans innovation are our base to develop, and we offer the best sale service for you.
