Silver Color 300mm Aluminum Triangle Truss For DJ Club

  • Silver Color 300mm Aluminum Triangle Truss For DJ Club
  • Silver Color 300mm Aluminum Triangle Truss For DJ Club
Place of Origin Guangzhou ,China
Brand Name LEDIKA
Model Number TRB30/40
Minimum Order Quantity 1 set
Price FOB，EXW
Packaging Details Air Bubble Film or carton
Delivery Time 2-3 weeks
Payment Terms L/C, T/T, Western Union, MoneyGram
Supply Ability 1000 pcs/per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model No. TRB30 / TRB40 Color Black,silver Or OEM
Material Aluminum Alloy 6082-T6 Application DJ, Club ,Concert,Exhibition,Events,Wedding,etc
Main Tube 50*3mm Shape Triangle
Length 0.5-4.0m And Customized Feature Heavy Load,convenient To Install And Dismounting,easy To Carry & Assemble & Take Apart,Good Welding,Non-rust
Brace Tube 25*2mm Connection Way Screw Connector
High Light

300mm Aluminum Triangle Truss

,

DJ Club Aluminum Triangle Truss

,

T6 Aluminum Triangle Truss
Leave a Message
Product Description



300mm Aluminum Triangle Truss For DJ Club Concert Indoor & Outdoor





1.Triangular Truss is used for DJ bar ,club , park;



2.Triangular Truss saves more space;



3.Comparing to SQB series ,TRS can lower the cost.



4. Comparing to TRS287/387,TRB30/40 is connected by screw.



TRB30 Allowable Loading
 6082-T6   50*3mm tube as main tube  25*2mm as brace tube
Span LOAD ALL Unitformly distributed load(UDL) Centre point load(CPL) 2 poits  3 poits 4 poits DEFLECTION
m ( ft )  kg kg/m kg kg  kg kg (mm)
4 13.1 781.4 195.4 390.7 293 195.4 162.6 5
5 16.4 624.8 125 312.4 234.3 156.2 130 13
6 19.7 522.7 87.1 261.4 196 130.7 108.8 22
7 23 443.5 63.4 221.8 166.3 110.9 92.2 33
8 26.2 387.2 48.4 193.6 145.2 96.8 80.5 45
9 29.5 340.6 37.8 170.7 128 85.4 71.1 59
10 32.8 308 30.8 154 115.5 77 64 75
11 36 280.7 25.5 140.8 105.6 70.4 58.6 92
12 39 253.4 21.1 126.7 95 63.4 52.7 110







TRB40 Allowable Loading
 6082-T6   50*3mm tube as main tube  30*2mm as brace tube
Span LOAD ALL Unitformly distributed load(UDL) Centre point load(CPL) 2 poits  3 poits 4 poits DEFLECTION
m ( ft )  kg kg/m kg kg  kg kg (mm)
4 13.1 951 237.8 444.4 333.3 222.2 184.9 9
5 16.4 888.8 177.8 444.4 333.3 222.2 184.9 14
6 19.7 887 147.8 443.5 332.6 221.8 184.6 23
7 23 874.7 125 437.4 328 218.7 181.9 34
8 26.2 767.4 95.9 383.7 287.8 191.8 159.6 45
9 29.5 681.1 75.7 340.6 255.4 170.3 141.7 53
10 32.8 616 61.6 308 231 154 128.2 77
11 36 561.4 51 280.7 210.5 140.4 116.8 78
12 39.2 517.4 43.1 258.7 194 129.4 107.6 97





Silver Color 300mm Aluminum Triangle Truss For DJ Club 0



Silver Color 300mm Aluminum Triangle Truss For DJ Club 1
