500 People Transparent Marquee Wedding Party Tent Aluminum Structure

500 People Aluminum Structure Transparent Marquee Wedding Party Tent

Material Description

(1) Frame structure: Hard pressed extruded aluminium 6061 /T6(15HW) which can last 15 to 25 years.
(2) Fabric cover: High quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV
resistant, tear resistant, self-cleaning ability, etc.
(3) Connector: Strong hot-DIP galvanized steel

Structural system

The main material is aluminum alloy profile GB6061-T6 / AL6082-T6. The support between the columns is reinforced with diagonal steel tubes. The length distance between the columns can be divided into 5 meters or 3 meters indefinitely.
The overall structure has passed the wind test of a professional institution. The maximum allowable wind speed is DIN EN 13782: 102 km / h (0.50kN / m).

Roofing system

The roof is made of excellent double-sided PVC coated synthetic fiber cloth material.
The tarpaulin has strong anti-corrosion, anti-mildew, anti-ultraviolet and flame retardant properties, and the flame retardancy is in accordance with DIN 4102 B1, M2; BS7837 / 5438; American NFPA70, etc. have reached international standards. The longest service life of tarpaulin is 10 years

Base System

The tents have no special requirements for the construction site, and generally flat grounds such as sand, grass, asphalt, cement and tile floors can be safely used.
It is suitable for rapid installation or disassembly in different environments. It has good flexibility and safety. It can be widely used in outdoor activities, commercial exhibitions, festivals, catering and entertainment, industrial storage, sports venues and so on.

Features

(1) Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
(2) Wind load: Max. 80km/h (can be reinforced)
(3) Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
(4) Easy to be assembled and dismantled, movable.
(5) No pole inside, 100% available interior space.

Optional accessories

(1) Covers: Colourful cover, transparent cover, inflatable roof cover
(2) Windows: Dome or square clear PVC windows, mesh window, glass window for glass wall
(3) Wooden flooring system: VIP cassette flooring, simple cassette flooring
(4) Doors: Double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
(5) Wall: Soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
(6) Fixing methods: Ground anchors, weight plate, expandable bolts
Rain gutters (inner roof beam rain gutter or rain gutter between two similar tents)
(7) Other optional items: Table, chair, lighting, AC, carpet, installation tools etc.

Why choose LEDIKA-truss ?

1.20-year's experience in truss and stage industry.
2. Customers from more than 150 countries.
3. We are manufacture, can offer you lower price.
4. Professional engineers offer technical support to customers.
5. 24hours online services from our professional foreign trade department.
6. All our raw material is from public company.
7. Our complete QC system can make sure every product with high quality.
Choosing LEDIKA Truss, you will get not only the products, but also the better service, and better operating mode.

►Our Products

►Our Projects

FAQ :
Q. Does LEDIKA accept OEM/ODM service ?
Yes , you can custom design or selected our design (OEM /ODM is high welcome) , our factory have professional design team and can do as your offered design .
Q.How to get samples from LEDIKA?
a.If you need samples for quality check , sample fees should be charged from buyer .
b.Free sample are available when order confirmed.
c.Most of the sample fees will be returned to you when order confirmed.
Q. What is the delivery time ?
7-15 days for batch goods regular size truss are in stock . Urgent order is also available.
Q. What is your trade terms?
Our trade terms are Ex-work , FOB , CNF & CIF
Q. Where is your factory and how can I visit your company ?
Ledika is a professional manufacturer in stage equipment, located in Nansha ,Guangzhou ,GuangDong , China . Warmly welcome you come to visit our factory .
Q. What advantage do you have to make me choose LEDIKA stage truss ?
We are a true factory & specialized in producing aluminum truss & other performance equipment more than 13 years . Humanist ans innovation are our base to develop, and we offer the best sale service for you .
