290mm Exhibit Aluminum Spigot Truss For Indoor Events
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model No. | SQS290 | Material | Aluminium 6061-T6/6082-T6 |
|---|---|---|---|
| Main Tube | Diameter 50*3mm | Bruce Tube | Diameter 20*2mm/25*2mm/30*2mm |
| Color | Black Or Customized,Silver | Connection Way | Spigot-Connector |
| Connector | Events ;Exhibition ,Music,Performance,Events,Concert | Feature | Heavy Load,convenient To Install And Dismounting,easy To Carry & Assemble & Take Apart,Good Welding,Non-rust |
| Max-Load | 12m | ||
| High Light | Exhibit Aluminum Spigot Truss,290mm Aluminum Spigot Truss,Event Aluminum Spigot Truss |
||
Product Description
290mm Exhibit Truss Aluminum Spigot Truss For Indoor Or Outdoor Events
SQS Series truss are connected by spigots.It's easy to set by hammer.Nice ,Fast, Easy, Saving time and Saving labor.It's suitable for mobile events,tower of Medium project and ceiling system indoor.Meanwhile ,widely used for exhibition truss .Available size:450*450/400*400/387*387/287*287mm. There are 2 style for SQS series truss,ordinary one with brace and indoor one without brace .They have their respective pictures for reference . Ordinary type's characteristic is that , when SQS is choosed as tower,its brace's design can make you climb aluminum truss conveniently ,comfortably ,safely. So ordinary aluminum truss is generally choosed and used as team or tower. Indoor type's characteristic is that its design has no brace, so when it is choosed and used as tower,it is not smooth and comfortable to climb .So it is not suitable as tower.Its brace is fully adopted "△" type,when it is used as ceiling or beam,you will see other kinds of aluminum trusses can't be comparable with its slinky degree.But all the trusses have sameness:they have brace, two tilted pipes derive from "▽",because each "△"type,structures a triangle,its stability can greatly strengthen aluminum metal safety factor.
| Truss section specification | ||||
| Size of Truss | 290*287mm | 390*390mm | 400*600mm | 450*450mm |
| connection | Spigot | Spigot | Spigot | Spigot |
| Truss main tube | Diameter Ø 50mm , Thickness 3mm | Diameter Ø 50mm , Thickness 3mm | Diameter Ø 50mm , Thickness 3mm | Diameter Ø 50mm , Thickness 3mm |
| standpipe | Φ20*2mm | Φ30*2mm | Φ30*2mm | Φ30*2mm |
| Truss Brace tube | Diameter Ø 20mm , Thickness 2mm | Diameter Ø 30mm , Thickness 2mm | Diameter Ø 30mm , Thickness 2mm | Diameter Ø 30mm , Thickness 2mm |
| Truss Joint | Diameter Ø 50mm | Diameter Ø 50mm | Diameter Ø 50mm | Diameter Ø 50mm |
| Max Loading | 520-800kg | 690-930kg | 690-930kg | 790-1100kg |
| Max Span | 12m | 16m | 16m | 18m |
The primary color of the aluminum alloy truss is silver, we can customize other colors according to your needs, such as black, gold, red, green...As the picture show,it is a set of golden truss for a disco.
Our Advantage:
1) Flexible : with the advantages of beautiful appearance , small volume and easy to set up , easy to assemble and disassemble
2) Customized Product : spigot or screw as your request, it is convenient for set up and transport
3) High quality Standard :capacity and stability of aluminum truss is strong to lift the speaker and light
4) Good Service : provide 24hours truss and stage hotline service.
5) Wide Usage : concert ,show, exhibition ,shoes fair, big cloth exhibition and any other outdoor show
6) All kinds of truss can retread and reused because of high corrosion resistance, non-rust with high welding and good quality of aluminum tube.
